Volume: 24m3
Tipping Angle: 45-50 Degree

Hydraulic System

Hydraulic Cylinder: 5 or 6 stage tilting Heavy Duty Cylinder


Type: Half Pipe Type
Floor Thickness: 8mm – HARDOX 450
Side Wall Thickness: 10mm – HARDOX 450
Front Wall Thickness: 8mm – HARDOX 450
Rear Door Thickness: 8mm – HARDOX 450
Chassis: S355 -St52 “U section” High Quality
Rear Door Mechanism: Hydraulic


Surface cleaning and sandblating process before painting. Then two layer coating and final paint process getting done in special cabinet.

Optional Specifications

Truck: 6×4 8×4
Volume: 14m3/16m3/18m3/20m3 20m3/22m3/24m3/26m3
Hydraulic Cylinder: Hidromas/Hyva/ Ozcelik
Rear Door: Manuel/ Chain Mechanismi
Bin: Box type


Mudguard: PVC or Steel
Spare Wheel Holder: Optional
Toolbox: Yes
Water Tank: Yes, 30 Lt
Fire Extinguisher Box: Yes
Tekerlek Takozu: Yes
Ladder: Optional
