Axle Load Capacity: 36000 Kg
Dead Weight: ~ 5500 Kg
Chassis: S355- St52 High Quality Steel
Platform: High Quality Steel
King Pin: 2’’ According to DIN standard
Front Wall: Fixed

Axle and Wheels

Axle Brand: TRAX
Number of Axles: 3
Suspension Pnoumatic: Suspension
Axle Lift: Optional
Steerable Axle: Yes
Tire Size: 385/65 R 22.5
Spare Wheel: Optional
Rims: Steel
Brakes: Disc
Brake System: WABCO brand EBS system

Standard Accessories

Tool Box: Yes
Mudguard: Yes
Water Tank: Yes
Fire Extinguisher Box: Yes
Side Protection Bar: Yes- Aluminum
Wheel Chocks: Yes
Landing Legs: Yes

Electric System

Electric & Lighting System: ASPOCK, SABA or SERTPLAS brand 2×7 pin socket 24V, Stop, Position and Tail lights according to EU standards.


Surface cleaning and sandblating process before painting. Then two layer coating and final paint process getting done in special cabinet.

Optional Specifications

Number of Axles: 2,3,4 Axle
Axle Brand: BPW- SAF – OSMAN KOC
Chassis: MC700
Tires: Double or Single
Suspension: Mechanical Suspension
Brakes: Kampanalı
Platform: Plywood
